Catia V56r2015 Basics Part Ii Part Modeling Tutorial Books Tutorial Books by Tutorial Books instant download after payment.

English | 2015-09-01 | ASIN: B014T7CFBQ | 242 Pages |This book is a continuation of CATIA V5-6R2015-Part I. The topics covered in this book are listed below:Basic Sketch Based Features
• Pad
• Shaft
• Project 3D Elements
• The Plane command
• Offset from plane
• Parallel through Point
• Through three points
• Through two lines
• Through point and line
• Through planar curve
• Normal to curve
• Tangent to surface
• Equation
• Mean through points
• Coordinates
• On curve
• On Plane
• On Surface
• Circle/Sphere/Ellipse center
• Tangent on curve
• Between
• Line
• Additional options of the Pad and Pocket commands
• Limits
• Thick
• View commands
• Measure CommandsHoles and Dress-Up Features
• Hole
• Simple Hole
• Counterbored Hole
• Countersunk Hole
• Tapered Hole
• Threaded Hole
• The Thread/Tap command
• The Edge Fillet command
• Limiting element(s)
• Blend corner(s)
• Variable Radius Fillet
• Chordal Fillet
• Face-Face Fillet
• Tritangent Fillet
• The Chamfer command
• Draft Angle
• Draft Reflect Line
• Variable Angle Draft
• ShellPatterned Geometry
• The Mirror command
• Rectangular Pattern
• Circular Pattern
• User Pattern
• Scaling
• AffinityRib Features
• The Rib command
• The Slot commandMulti Section Solids
• The Multi-sections Solid command
• Types of the Cross-sections
• Couplings
• Spines
• Guides
• Relimitation
• Removed Multi-sections SolidAdditional Features and Multibody Parts
• Stiffener
• Solid Combine
• Multi-body Parts
• Creating Multi-bodies
• Insert in new body
• Assemble
• Add
• Remove
• Intersect
• Union Trim
• Remove LumpModifying Parts
• Edit Sketches
• Edit Feature Definition
• Edit Feature Parameters
• Deactivate Features
• Activate Features
• Changing the Sketch Support
