Dynamic Circuit Response Analog Circuit Design Volume 2 1st Edition Dennis L Feucht by Dennis L. Feucht instant download after payment.

This second volume, Analog Circuit Design: Designing Dynamic Circuit Response, builds upon the first volume (Analog Circuit Design: Designing Amplifier Circuits) by extending coverage to include reactances and their time- and frequency-related behavioral consequences. Retaining a design-oriented analysis, this volume begins with circuit fundamentals involving capacitance and inductance and lays down the approach using s-domain analysis. Additional concepts and perspectives fill in the blanks left by textbooks in regards to circuit design. It simplifies dynamic circuit analysis by using the graphical methods of reactance plots. Methods of compensating amplifiers, including feedback amplifiers, are kept as simple as possible using reactance plots and s-domain transfer functions that mainly require algebraic skill.
Contents
Transient and Frequency Response 1
Dynamic Response Compensation 73
High-Frequency Impedance Transformations 168
Closure  & References 208
