Esdajedec Joint Standard For Electrostatic Discharge Sensitivity Testing Eosesd Association by Eos/esd Association, Inc. instant download after payment.

The earliest electrostatic discharge (ESD) test models and standards simulate a charged object approaching a device and discharging through the device. The most common example is the human body model (HBM). However, with the increasing use of automated device handling systems another potentially destructive discharge mechanism, the charged device model (CDM) becomes increasingly important. In the CDM a device itself becomes charged (e.g., by sliding on a surface (tribocharging) or by electric field induction) and is rapidly discharged (by an ESD event) as it closely approaches a conductive object. A critical feature of the CDM is the metal-metal discharge which results in a very rapid transfer of charge through an air breakdown arc. The CDM test method also simulates metal-metal discharges arising from other similar scenarios, such as the discharging of charged metal objects to devices at different potential.
