Microwave Circuit Design Using Linear And Nonlinear Techniques Second Edition George D Vendelin by George D. Vendelin, Anthony M. Pavio, Ulrich L. Rohde(auth.) 9780471414797, 9780471715832, 0471414794, 0471715832 instant download after payment.

The ultimate handbook on microwave circuit design with CAD. Full of tips and insights from seasoned industry veterans, Microwave Circuit Design offers practical, proven advice on improving the design quality of microwave passive and active circuits-while cutting costs and time. Covering all levels of microwave circuit design from the elementary to the very advanced, the book systematically presents computer-aided methods for linear and nonlinear designs used in the design and manufacture of microwave amplifiers, oscillators, and mixers. Using the newest CAD tools, the book shows how to design transistor and diode circuits, and also details CAD's usefulness in microwave integrated circuit (MIC) and monolithic microwave integrated circuit (MMIC) technology. Applications of nonlinear SPICE programs, now available for microwave CAD, are described. State-of-the-art coverage includes microwave transistors (HEMTs, MODFETs, MESFETs, HBTs, and more), high-power amplifier design, oscillator design including feedback topologies, phase noise and examples, and more. The techniques presented are illustrated with several MMIC designs, including a wideband amplifier, a low-noise amplifier, and an MMIC mixer. This unique, one-stop handbook also features a major case study of an actual anticollision radar transceiver, which is compared in detail against CAD predictions; examples of actual circuit designs with photographs of completed circuits; and tables of design formulae.Content:
Chapter 1 RF/Microwave Systems (pages 1–34):
Chapter 2 Lumped and Distributed Elements (pages 35–50):
Chapter 3 Active Devices (pages 51–191):
Chapter 4 Two?Port Networks (pages 192–240):
Chapter 5 Impedance Matching (pages 241–272):
Chapter 6 Microwave Filters (pages 273–310):
Chapter 7 Noise in Linear Two?Ports (pages 311–387):
Chapter 8 Small?and Large?Signal Amplifier Design (pages 388–432):
Chapter 9 Power Amplifier Design (pages 433–519):
Chapter 10 Oscillator Design (pages 520–723):
Chapter 11 Microwave Mixer Design (pages 724–868):
Chapter 12 RF Switches and Attenuators (pages 869–890):
Chapter 13 Microwave Computer?Aided Workstations for MMIC Requirements (pages 891–958):
