Pcb Design Guide To Via And Trace Currents And Temperatures Douglas Brooks

Name: Pcb Design Guide To Via And Trace Currents And Temperatures Douglas Brooks
SKU: BELL-33356336
Price: 31.00 USD
Availability: InStock
Rating: 5 (78 reviews)

SKU: BELL-33356336

$ 31.00 ~~$ 45.00~~ (-31%)

5.0

78 reviews

Pcb Design Guide To Via And Trace Currents And Temperatures Douglas Brooks instant download after payment.

Publisher: Artech House

File Extension: PDF

File size: 7.33 MB

Pages: 306

Author: Douglas Brooks, Johannes Adam

ISBN: 9781630818609, 1630818607

Language: English

Year: 2021

Product desciption

Pcb Design Guide To Via And Trace Currents And Temperatures Douglas Brooks by Douglas Brooks, Johannes Adam 9781630818609, 1630818607 instant download after payment.

A very important part of printed circuit board (PCB) design involves sizing traces and vias to carry the required current. This exciting new book will explore how hot traces and vias should be and what board, circuit, design, and environmental parameters are the most important. PCB materials (copper and dielectrics) and the role they play in the heating and cooling of traces are covered. The IPC curves found in IPC 2152, the equations that fit those curves and computer simulations that fit those curves and equations are detailed.
Sensitivity analyses that show what happens when environments are varied, including adjacent traces and planes, changing trace lengths, and thermal gradients are presented. Via temperatures and what determines them are explored, along with fusing issues and what happens when traces are overloaded. Voltage drops across traces and vias, the thermal effects going around right-angle corners, and frequency effects are covered. Readers learn how to measure the thermal conductivity of dielectrics and how to measure the resistivity of copper traces and why many prior attempts to do so have been doomed to failure. Industrial CT Scanning, and whether or not they might replace microsections for measuring trace parameters are also considered.
