Sparameters For Signal Integrity Peter J Pupalaikis by Peter J. Pupalaikis 9781108489966, 1108489966 instant download after payment.

Master the usage of s-parameters in signal integrity applications and gain full understanding of your simulation and measurement environment with this rigorous and practical guide. Solve specific signal integrity problems including calculation of the s-parameters of a network, linear simulation of circuits, de-embedding, and virtual probing, all with expert guidance. Learn about the interconnectedness of s-parameters, frequency responses, filters, and waveforms. This invaluable resource for signal integrity engineers is supplemented with the open-source software SignalIntegrity, a Python package for scripting solutions to signal integrity problems.
Contents
Preface page  xiii
Abbreviations  xvi
Introduction  1
Part I Scattering Parameters  5
1  Network Parameter Models  7
2  Waves  29
3  Scattering Parameters  41
4  S-Parameter System Models  82
5  Reference Impedance  134
6  Sources  152
7  Transmission Lines  178
Part II   Applications  215
8  System Descriptions  217
9  Simulation  260
10 De-embedding  282
11 Virtual Probing  319
Part III  Signal Processing and Measurement  355
12 Frequency Responses, Impulse Responses, and Convolution  357
13 Waveforms and Filters  404
14 The Impedance Profile  440
15 Measurement  457
16 Model Extraction  512
Part IV  Signallntegrity 533
17 Signallntegrity.Lib Package  537
18 SignallntegrityApp  562
Afterword  590
Appendix A  Terminology and Conventions  592
Appendix В  Telegrapher's Equations  595
Appendix C  Matrix Algebra  598
Appendix D  Symbolic Device Solutions  608
References  631
Index  636
