The Construction Of A Large Wheel Skeleton Clock John Wilding

  • SKU: BELL-50911606
The Construction Of A Large Wheel Skeleton Clock John Wilding
$ 31.00 $ 45.00 (-31%)

4.3

8 reviews

The Construction Of A Large Wheel Skeleton Clock John Wilding instant download after payment.

Publisher: Ritetime Publishing
File Extension: PDF
File size: 39.53 MB
Pages: 76
Author: John Wilding
Language: English
Year: 2001

Product desciption

The Construction Of A Large Wheel Skeleton Clock John Wilding by John Wilding instant download after payment.

The main features of this most attractive clock are the simplicity in the design of the inverted Y frames together with the large main wheel. Despite its size this wheel was cut in the author's Myford ML 7 lathe. A further interesting feature to note is the equal size of both the third and escape wheels. This balances the upper part of the clock. The movement is driven by a mainspring in a going barrel and optional stopwork is described in the text.

There are 64 pages and 137 drawings and photographs.

When cutting out the frames allow extra material around the diamond area to alter the shape after depthing, allow the diamond shape to be moved up or down a little do not finish the diamond shape as per plan before depthing.

Cutters Module 0.75, 0.6, 0.55

Mr Wilding pinion sizes are 8 leaf 0.279", 7 leaf 0.206"
